GigBAR Bridge ILS Swarm Package
GigBAR Bridge ILS Swarm Package
Fill the room with the GigBAR Bridge ILS Swarm Package – the ultimate all-in-one lighting solution.
This powerful system includes two heavy-duty lighting stands, ILS Command controller, 2 x Swarm 5FX ILS and a pair of GigBAR Bridge ILS fixtures, each equipped with 2 moving heads and 4 hex-colour wash LEDs for a total of 4 moving heads and 8 vibrant washes.
Setup is effortless thanks to the ILS (Integrated Lighting System) technology, which automatically synchronises all fixtures for a perfectly coordinated light show – no programming or DMX knowledge required.
With adjustable stand heights ranging from 1.5m to 3.6m, the GigBAR Bridge ILS can be deployed in almost any venue, delivering a dynamic, professional-grade light show that’s as easy to set up as it is impressive to watch.
- GigBAR Bridge ILS
Transform your stage or venue with a sleek, all-in-one lighting system designed for mobile entertainers, DJs, and live performances. The GigBAR Bridge ILS delivers dynamic effects, wireless control, quick setup and effortless integration. Featuring two 40 Watt beam moving heads and four 10 Watt RGBAW + UV LED wash lights this GigBAR Bridge ILS packs a sophisticated light show into a single convenient fixture.
- 2-in-1 design: Combines dual 40 W cool-white moving heads with four hex-colour (RGBAW+UV) wash LEDs, all pre-mounted on one compact crossbar.
- Wireless freedom: Built-in D-Fi transceiver enables seamless DMX or ILS control, extending range up to 180 m (600 ft).
- Integrated Lighting System (ILS): Sync multiple fixtures effortlessly—ILS enables coordinated shows across your entire lighting ecosystem.
- Totem Mode: Fixes moving heads downward for immersive dance-floor coverage.
- Power Linkable: Run up to 8 units on 120 VAC or 13 units on 230 VAC using a single power source—no need for extension cords.
- Full DMX Control: Choose from 3, 16 or 46-channel DMX personality; includes display + menu buttons, RF & footswitch binding.
- Robust build & setup: Auto-ranging power supply (100–240 VAC), compact size (660 × 71 × 305 mm), weighs just 8.4 kg—easy to mount on truss or tripod.
- Included items: Comes supplied with 2 hanging brackets and a transportation bag.
- Specifications
- DMX Channels: 3, 16 or 46DMX
- Connectors: 3-pin XLR
- Strobe Rate: 0 to 20Hz
- Operating Frequency: 2.4 GHZ
- Power Linking: 8 units @ 120 V; 13 units @ 230 V
- Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
- Weight: 18.6 lbs (8.4 kg)
- Size: 26 x 2.8 x 12 in (660 x 71 x 305 mm)
- Approvals: CE, RoHS , FCC
- Colours (moving head): 9 + open, split colours, continuous scroll at variable speeds
- Gobos (moving head): 9 + open, continuous scroll at variable speeds
- Light Source (moving head): 1 LED (cool white) 40W (3A), 50,000 hours life expectancy.
- Light Source (wash): 4 LEDs (hex-color RGBAW + UV) 10W (1.3 A), 50,000 hours life expectancy.
- Beam Angle (wash): 22°
- Field Angle (wash): 38°
- Power and Current: 191 W, 1.5 A @ 120 VAC, 60Hz
- Power and Current: 175 W, 1 A @ 230 VAC, 50Hz
- Fits Tripod Sizes: 1.5 in (37.4 mm)
- Max Unobstructed Distance (D-Fi): 600 ft (183 m)
- Optional Controllers: RF, Footswitch, ILS Command
- Illuminance (moving head): 6,594 Lux @ 2 m (per head)
- Illuminance (wash): 375 lux @ 2 m (per section)
- Swarm 5FX ILS
Your parties deserve the excitement of Swarm 5 FX ILS. This 3-in-1 LED light that includes an RGBAW rotating derby, red/green laser, and white strobe effect and compatibility with the cutting edge Integrated Lighting System (ILS) that makes creating coordinated light shows across different fixture types easy. Swarm 5 FX ILS also features D-Fi USB compatibility for wireless Master/Slave or DMX control. Flexibility is even greater with automated and sound-activated programs, or Master/Slave and DMX modes and separate colour and program control.
Features
- 3-in-1 LED light that includes an RGBAW rotating derby, red/green laser, and white strobe effect
- ILS compatibility for use in the ILS ecosystem
- D-Fi USB compatibility for wireless Master/Slave or DMX control
- Laser projects thousands of red and green laser beams
- Operation allows for separate colour and program control
- Increase control options using automated and sound-activated programs, or Master/Slave and DMX modes
- Save time running cables and extension cords by power linking multiple units
- Fits best inside the CHS-40 VIP gear bag
- ILS Command
Are you tired of lengthly set up and programming of your lighting system? Then ILS Command is the answer. This new lighting controller from Chauvet DJ has been specifically designed to control their new ILS range of fixtures in a quick and intuitive way that makes creating a synchronised light show across different fixture types fast and easy without DMX. Now the ILS universe is at your command with ILS Command, a powerful controller capable of programing any ILS-enabled product. This hardware controller has a built-in D-Fi transmitter that wirelessly controls any number of ILS-enabled fixtures. Enjoy unlimited creativity as you customize, save and recall presets even in dark environments where backlit silicon buttons provide a tactile response and bright visibility. Your lighting creations are always safe because you can back up, restore and update the controller’s software using the built-in USB port and ensure unauthorised access is blocked by enabling the onboard lockout. An innovative follow spot mode highlights grand entrances without interrupting the rest of the show and a built-in audio connector allows for better accuracy when triggering lights to the beat. Manually override the show on the fly using the 9 quick colour access buttons. Safely transport the controller with the included carry case.
